Inquiry:
2×0.22mm² Security Alarm Cable
- Conductor:Electrolytic Copper Conductor
- MOQ:10KM
- Use:indoor signal and data transfer
- Packing: roll, wooden spool, carton, pallet
- Product description: 2×0.22mm² Security Alarm Cable
Product Description:
2×0.22mm² Security Alarm Cable
This type of cable are use fixed indoor installations and signal communicaiton. The screen protects the cable core against electrical noises and interferences.
Conductor: 2 x (7/0.20mm TC/BC/CCA/TCCA)
Dielectric:Type PVC
Diameter: 0.95mm
Color Code: 1Black 2Red
Drain Wire:7 x 0.20mm (TC/BC/CCA/TCCA)
Shield:Aluminum Foil
Rip Cord:Cotton Wire
Jacket: 3.10mm PVC
Electrical Properties :
Temperature Rating
（-20℃ ~ +60℃）
Operating Voltage
300 Volts max
Capacitance
45pf/ft nom.
Impedance
40 Ohms nom.
DC Resistance
16.5 Ohms/M' at 20℃
